200 tonnes an hour.*
On 8–9 litres of diesel.*
Compact, easy to move at 26 tonnes, and cheap to run. Ask us and we'll show you.
*Maximum figures. Output and fuel use vary with material, feed size, jaw setting and site conditions.
Run it on diesel –
8–9 litres an hour.*
Or plug it in –
no diesel at all.
Big output from a compact crusher.
Hand-built in the UK, the JTEC 963+ crushes up to 200 tonnes an hour through its 900 × 630 mm jaw on just 8–9 litres of diesel.
At 26 tonnes it’s compact and easy to move, and with Dual Power you can switch from the diesel engine to your own mains supply and cut running costs even further.
How much are you burning?
Put in your numbers. We’ll show you what the same hours cost on a JTEC 963+ – and how much you could save.
litres of diesel
litres of diesel at about 9 L/hr
Estimate based on the JTEC 963+ at about 9 L/hr. Real fuel use varies with material, feed size, jaw setting and site conditions.
JTEC 963+ specs
Crusher
- Jaw size
- 900 × 630 mm (36" × 25")
- Max output
- up to 200 tph
- Jaw setting (CSS)
- 40–120 mm (1½"–4¾")
- Crusher speed
- 280–300 rpm
- Drive
- Hydraulic, reverse crush
- Adjustment
- Manual hydraulic
- Jaw plates
- Reversible
Power & fuel
- Engine
- 4-cylinder diesel
- Dual Power
- Run on mains electric
- Fuel use
- 8–9 L/hr (2.1–2.4 US gal)
- Controls
- Radio remote, Auto Run
Feed hopper
- Feeder
- Vibratory, variable speed
- Feeder length
- 2.9 m (9.6 ft)
- Hopper capacity
- 3 m³ (106 ft³)
Main conveyor
- Width
- 800 mm (2.62 ft)
- Discharge height
- 2.8 m (9.17 ft)
- Belt speed
- 1.6 m/sec
- Access
- Hydraulic lowering
- Also fitted
- Overband magnet, side belt
Dimensions & weight
- Transport L × W × H
- 11.42 × 2.50 × 3.27 m
- 37' 6" × 8' 2" × 10' 9"
- Working width
- 3.80 m (12' 6") with side belt
- Weight
- 26,000 kg (57,300 lb)
Want it all on one page? Download the spec sheet, or ask us to build it to your spec.
Maximum figures shown. Output and fuel use vary with material type and hardness, feed size, jaw setting and site conditions. Specifications may change without notice.
